LP SERIES HOLOGRAPHIC INVISIBLE LED SCREEN
Where Light Lives in Architecture
The LP Series is InVisia’s flagship holographic transparent LED display designed specifically for permanent installations. With transparency up to 90%, ultra-lightweight panels starting from only 1.15 kg, and a slim profile as thin as 1.8 mm, LP Series creates floating holographic visuals while maintaining natural daylight and visibility. Available in 2.0mm, 2.9mm, 3.9mm and 6.25mm pixel pitches, it offers flexible solutions for projects of every size. Built with a 4-layer PCB and 2oz copper thickness, it delivers superior heat dissipation, ensuring higher brightness and long-lasting performance.
Key Features & Advantages
Super-lightweight
Weight only 4.6kg/sqm
80% Transparency
See beyond the screen
HD Display Quality
Even pixel spacing, integrated LEDs and driver, 16-bit grayscale.
Remote Control
Smart Cloud Management. Control, update, and monitor your display anytime, anywhere.
High-contrast display
Black LEDs. Pure contrast.
Modular Replaceable Design
Flexible Surface Mounting. Easily replace LED modules.
LP Holographic LED Displays
Multi-Installation Flexibility
LP Series holographic invisible LED screen is engineered for lightweight, flexible installation. It can be installed directly onto glass surfaces without visible supporting structures. For projects where glass mounting isn’t suitable, the LP Series also supports hanging installations and freestanding configurations with lightweight die-cast aluminum frames.
Lightweight Modular Design
LP Series holographic invisible LED screen is available in both standard and custom configurations. Standard mesh LED panels measure 250 mm wide with heights of 1000 mm, 1200 mm, 1500mm, and 2400 mm, making them easy to combine into displays of almost any size, and to create ultra-large transparent LED video walls. As a professional holographic transparent LED display manufacturer, InVisia also provides custom mesh LED panels tailored to your project dimensions.
Portable Framed Holographic LED Display for Demonstrations
For product demonstrations, customer presentations, or sample evaluation, the InVisia LP Framed Series is the ideal solution. Built with a lightweight yet durable aluminum frame, it offers the same outstanding image quality and transparency as the standard LP Series while providing greater portability and ease of setup. Standard sample sizes of 0.5 m² and 1 m² are supplied with a protective flight case, making transportation safe and convenient.
SPECS
LP SERIES SPECIFICATION
| Model | LP-P2.0-1045 | LP-P2.9-1025 | LP-P2.9-1200 | LP-P2,9-1500 | LP-P2,9-2400 | LP-P3.91-1025 | LP-P3.91-1200 | LP-P3.91-1500 | LP-P3.91-2400 | LP-P6.25-1025 | LP-P6.25-1200 | LP-P6.25-1500 | LP-P6.25-2400 | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Pixel Pitch | 2.0 mm | 2.9 mm | 2.9 mm | 2.9 mm | 2.9 mm | 3.91 mm | 3.91 mm | 3.91 mm | 3.91 mm | 6.25 mm | 6.25 mm | 6.25 mm | 6.25 mm | ||||||||||||
| Pixel Density | 250,000 dot/ m² | 112,896 dot/ m² | 112,896 dot/ m² | 112,896 dot/ m² | 112,896 dot/ m² | 65,536 dot/ m² | 65,536 dot/ m² | 65,536 dot/ m² | 65,536 dot/ m² | 25,600 dot/ m² | 25,600 dot/ m² | 25,600 dot/ m² | 25,600 dot/ m² | ||||||||||||
| Visual Transparency | ＞70% | ＞80% | ＞80% | ＞80% | ＞80% | ＞80% | ＞80% | ＞80% | ＞80% | ＞90% | ＞90% | ＞90% | ＞90% | ||||||||||||
| Module Size ( mm ) | 1,045 × 200 | 1,025 × 250 | 1,200 × 250 | 1,500 × 250 | 2,400 × 250 | 1,025 × 250 | 1,200 × 250 | 1,500 × 250 | 2,400× 250 | 1,025 × 250 | 1,200 × 250 | 1,500 × 250 | 2,400 × 250 | ||||||||||||
| Screen Size ( mm ) | 1,045 × 200 × 72 | 1,047 × 250 × 72 | 1,222 × 250 × 72 | 1,522 × 250 × 72 | 2,422 × 250× 72 | 1,047 × 250 × 72 | 1,222 × 250 × 72 | 1,522 × 250 × 72 | 2,422 × 250× 72 | 1,047 × 250 × 72 | 1,222 × 250 × 72 | 1,522 × 250 × 72 | 2,422 × 250 × 72 | ||||||||||||
| LED Type | 1010 | 1818 | 1818 | 1818 | 1818 | 2121 | 2121 | 2121 | 2121 | 2121 | 2121 | 2121 | 2121 | ||||||||||||
| Weight | 2 kg | 1.43 kg | 1.55 kg | 1.72 kg | 2.25 kg | 1.4 kg | 1.46 kg | 1.55 kg | 2.07 kg | 1.15 kg | 1.25 kg | 1.42 kg | 1.65 kg | ||||||||||||
| Resolution | 500 × 100 pix | 336 × 84 pix | 392 × 84 pix | 492 × 84 pix | 784 × 84 pix | 256 × 64 pix | 300 × 64 pix | 376 × 64 pix | 600 × 64 pix | 160 × 40 pix | 188 × 40 pix | 236 × 40 pix | 376 × 40 pix | ||||||||||||
| Panel Thickness | 1.3 mm | 1.5 mm | 1.5 mm | 1.5 mm | 1.5 mm | 1.8 mm | 1.8 mm | 1.8 mm | 1.8 mm | 1.8 mm | 1.8 mm | 1.8 mm | 1.8 mm | ||||||||||||
| Brightness | 2,000 nits | 3,500 nits | 3,000 nits | 2,500 nits | 3,000 nits | 4,000 nits | 3,500 nits | 3,000 nits | 3,000 nits | 4,000 nits | 4,500 nits | 3,000 nits | 3,000 nits | ||||||||||||
| Max/Average Power(W/㎡) | 760 / 270 | 1,076 / 280 | 916 / 274 | 795 / 278 | 916 / 274 | 1,000 / 270 | 946 / 331 | 746 / 261 | 746 / 261 | 750 / 235 | 750 / 235 | 619 / 216 | 619 / 216 | ||||||||||||
| LED Control System | Synchronous / Asynchronous | ||||||||||||||||||||||||
| Playback Control Method | Input: HDMI、WiFi、Bluetooth,Built-in Playback System,32GB of storage,Cloud Management | ||||||||||||||||||||||||
| Viewing Angle | Horizontal 160, Vertical 140 | ||||||||||||||||||||||||
| White Balance Color Temperature | 5500K-15000K (adjustable) | ||||||||||||||||||||||||
| Attenuation Rate | 2 years below 0.05% | ||||||||||||||||||||||||
| MTBF (Mean Time Between Failures) | ≥ 100,000 hours | ||||||||||||||||||||||||
| Installation Method | Wall mount installation, glass adhesive, hanging, stacking, suitable for curved installations, supports cutting to any size. | ||||||||||||||||||||||||
| Packaging Method | Cardboard Case / Plywood Case / Flight Case | ||||||||||||||||||||||||
| Storage Humidity | 10%RH～85%RH,no condensation | ||||||||||||||||||||||||
| Operating Temperature | -20℃～+50℃ | ||||||||||||||||||||||||
| Operating Humidity | 20%RH～85%RH,no condensation | ||||||||||||||||||||||||
| Storage Temperature | -20℃ ~ +50℃ | ||||||||||||||||||||||||
| Breakpoint Resume | √ | ||||||||||||||||||||||||
| Average Lifetime | ≥ 100,000 hours | ||||||||||||||||||||||||
| Grayscale Level | ≥16 bit | ||||||||||||||||||||||||
□ Add to compare □ Add to compare
All specifications are per panel and for reference only; actual values may vary. Max hanging/stacking capacities are valid only with official InVisia Displays hardware and proper ballast (for stacking), as detailed in manuals/reports. A safety factor of 8 applies. Climbing is permitted only as specified in the panel manual.
