Soft LED Module

InVisia standardized soft LED module (320mm × 160mm) delivers ultra-flexible, high-contrast visuals for curved, cylindrical, and creative LED displays. Designed for stages, exhibitions, retail environments, and conference backdrops, it combines bendable performance, low power consumption, and robust structural stability.

Low Current & High Efficiency — Reduced power consumption without compromising brightness.
High Contrast: 5000:1 — Deep blacks and vivid colors for crisp, immersive visuals.
Ultra-Smooth Display Quality
High Brightness & Rich Grayscale
Refresh Rate ≥ 3840Hz
12–16bit Grayscale Processing
No Delays, Smearing, or Motion Shadows

Inquiry Now

Flexible Viewing & Curved Installation

Wide 160° Viewing Angle
Bends to Ø509mm to fit arcs, cylinders, or organic shapes
Ideal for curved LED walls, stage designs, exhibit columns, and creative wrap-around screens

Robust Structural Design

High-strength sandblasted iron cabinet
Segmented splicing reduces gaps
Strong magnetic adsorption installation

The bottom shell is made of premium silicone material, featuring excellent flexibility, high temperature resistance, low temperature protection, static elimination, and strong protective performance.

Inquiry Now

PCB, TG140 Standard

The PCB adopts TG140 standard substrate material, with special circuit layout and multilayer board process design, using high-grade materials to significantly reduce the “color temperature” phenomenon

Inquiry Now

Silicone Raw Material

The bottom shell is made of premium silicone material, featuring excellent flexibility, high temperature resistance, low temperature protection, static elimination, and strong protective performance.

Inquiry Now

During the installation and removal of modules, violent tearing is strictly prohibited to avoid damaging the PCB board due to excessive force;
The minimum bending diameter for flexible modules should be within 509mm, and repeated violent folding of the modules is strictly forbidden.

Technical Parameters:

Product Name		P1.25	P1.538	P1.568	P1.667	P1.86	P2	P2.5	P3.076	P4

Product Name	Pixel configuration	1R1G1B（Full color）
	LED packaging specifications	SMD1010	SMD1212				SMD1515	SMD1515	SMD1515	SMD2121
	Pixel density (dots/m²)	640000	422500	406406	360000	288906	250000	160000	105625	62500
	Module dimensions (mm)	320x160x5.25（Length x Height x Thickness）
	Module resolution	256x128	208x104	204x102	192x96	172x86	160x80	128x64	104x52	80x40
	Scanning method	1/64	1/52	1/51	1/48	1/43	1/40	1/32	1/26	1/20
	Refresh rate (Hz)	≥3000-3840						≥1920
	Frame rate (Hz)	50&60
	Gray level (bit)	12-16 Adjustable
	Signal interface method	HUB75
	Module base shell material	Silicone soft bottom case
	Module weight (kg/piece)	0.334	0.33	0.325	0.318	0.316	0.315	0.269	0.252	0.23
	Enclosure dimensions	Can be customized according to the module size
	Box material	Sheet metal sandblasted iron box
	Box flatness (mm)	≤ 0.3
	Protection level	IP45
	Installation/Maintenance Method	Support front and rear installation & front and rear maintenance
Optical properties	Brightness (nits)	650-800cd
	Color temperature (K)	3000—10000 Adjustable
	Brightness uniformity	≥97%
	Horizontal/vertical viewing angle	≥160°/≥140°
	Contrast	5000:01:00
Electrical parameters	Module power supply voltage DC (V)	5	5	5	5	5	5	5	5	5
	Maximum current of the module DC (A)	5	5	5	5	4.5	4.5	4.5	4.5	4.5
	Maximum power consumption of the module (w/piece)	25	25	25	25	22.5	22.5	22.5	22.5	22.5
	Working input voltage AC (V)	110-220 Customizable
	Module peak power consumption (W/m²)	490	490	490	490	440	440	440	440	440
	Module average power consumption (W/m²)	165	165	165	165	150	150	150	150	150
Electrical parameters	Typical lifetime (hrs)	100,000
	Operating temperature range (°C)	-10—50
	Storage temperature range (°C)	-20—60
	Operating humidity range (RH)	20—85%（Without condensation）
	Storage humidity range (RH)	20—80%（Without condensation）

Perfect for creative architecture, immersive stages, commercial displays, and curved installations. Want a detailed quote or custom design? Contact us to customize your soft LED display solution.

Inquiry Now
